Reference DS-K1801MK
Indoor/outdoor reader with keyboard/mifare card 13.56mhz
- Description
- Reviews (0)
Description
Specifications & Features
Series : HikA-P
Control Type : Reader
IDENTIFICATION
Keyboard : Yes
Mode : Keyboard / Card
Card Type : MIFARE 13.56MHz
Maximum reading distance : less than 50 mm
COMMUNICATION
Mode : Wiegand
CHARACTERISTICS
Integrated Controller : No
LED Indicator : Yes
Audible warning : Yes
SYSTEM (PRESENCE/ACCESS CONTROLS)
Main processor : 8-bit
MATERIAL & DIMENSIONS
Material : ABS Plastic + Polycarbonate
Dimensions : 87 x 87 x 13.3 mm
ENVIRONMENT
Operating Temperature : -20ºC ~ 65°C
Degree of protection : IP65
Usage : Indoor/Outdoor
Maximum humidity : 90%
FOOD & CONSUMPTION
Power Mode : DC
Voltage : 12V
Power Consumption (W) : 1.6W
Amperage : 150mA
